vue实现取景框

2026-01-20 13:44:33VUE

在Vue中实现取景框功能，通常用于图像裁剪、扫描识别等场景。以下是几种常见的实现方式：

基于Canvas的实现

通过Canvas绘制取景框，结合鼠标交互实现动态调整：

<template>
  <div class="viewport">
    <canvas ref="canvas" @mousedown="startDrag" @mousemove="onDrag" @mouseup="endDrag"></canvas>
    <div class="frame" :style="frameStyle"></div>
  </div>
</template>

<script>
export default {
  data() {
    return {
      frame: { x: 100, y: 100, width: 200, height: 200 },
      isDragging: false
    }
  },
  computed: {
    frameStyle() {
      return {
        left: `${this.frame.x}px`,
        top: `${this.frame.y}px`,
        width: `${this.frame.width}px`,
        height: `${this.frame.height}px`
      }
    }
  },
  methods: {
    startDrag(e) {
      this.isDragging = true
      this.dragStart = { x: e.clientX, y: e.clientY }
    },
    onDrag(e) {
      if (!this.isDragging) return
      const dx = e.clientX - this.dragStart.x
      const dy = e.clientY - this.dragStart.y
      this.frame.x += dx
      this.frame.y += dy
      this.dragStart = { x: e.clientX, y: e.clientY }
    },
    endDrag() {
      this.isDragging = false
    }
  }
}
</script>

<style>
.viewport {
  position: relative;
  width: 500px;
  height: 500px;
}
.frame {
  position: absolute;
  border: 2px dashed #fff;
  box-shadow: 0 0 0 10000px rgba(0,0,0,0.5);
}
</style>

使用第三方库

对于更复杂的取景框需求，可以使用专门的图像处理库：

安装cropperjs：

npm install cropperjs

Vue组件实现：

<template>
  <div>
    <img ref="image" src="your-image.jpg" alt="">
  </div>
</template>

<script>
import Cropper from 'cropperjs'
import 'cropperjs/dist/cropper.css'

export default {
  mounted() {
    this.cropper = new Cropper(this.$refs.image, {
      aspectRatio: 16 / 9,
      viewMode: 1,
      autoCropArea: 0.8,
      guides: true,
      center: true,
      highlight: false,
      cropBoxMovable: true,
      cropBoxResizable: true
    })
  },
  beforeDestroy() {
    this.cropper.destroy()
  }
}
</script>

纯CSS实现

简单的静态取景框可以通过CSS实现：

<template>
  <div class="camera-view">
    <div class="frame"></div>
  </div>
</template>

<style>
.camera-view {
  position: relative;
  width: 100%;
  height: 100vh;
  background: rgba(0,0,0,0.7);
}
.frame {
  position: absolute;
  top: 50%;
  left: 50%;
  transform: translate(-50%, -50%);
  width: 70%;
  height: 50%;
  border: 2px solid white;
  box-shadow: 0 0 0 100vmax rgba(0,0,0,0.5);
}
</style>

结合WebRTC实现实时取景

对于摄像头实时取景场景：

<template>
  <div class="camera-container">
    <video ref="video" autoplay playsinline></video>
    <div class="overlay-frame"></div>
  </div>
</template>

<script>
export default {
  mounted() {
    navigator.mediaDevices.getUserMedia({ video: true })
      .then(stream => {
        this.$refs.video.srcObject = stream
      })
  },
  beforeDestroy() {
    const stream = this.$refs.video.srcObject
    stream.getTracks().forEach(track => track.stop())
  }
}
</script>

<style>
.camera-container {
  position: relative;
}
.overlay-frame {
  position: absolute;
  top: 50%;
  left: 50%;
  transform: translate(-50%, -50%);
  width: 300px;
  height: 300px;
  border: 2px solid red;
  pointer-events: none;
}
</style>

以上方法可根据具体需求选择使用，Canvas方案适合需要自定义交互的场景，第三方库提供更完整的图像处理功能，CSS方案适合简单静态展示，WebRTC方案适用于实时摄像头取景。
