react实现标尺刻度

2026-01-26 17:26:53React

实现标尺刻度的方法

在React中实现标尺刻度可以通过多种方式完成，以下是几种常见的方法：

使用CSS和Flexbox布局

通过CSS的Flexbox布局可以轻松实现水平或垂直标尺刻度。定义一个容器元素，使用Flexbox均匀分布刻度线。

import React from 'react';
import './Ruler.css';

const Ruler = ({ length, orientation }) => {
  const ticks = Array.from({ length }, (_, i) => i);

  return (
    <div className={`ruler ${orientation}`}>
      {ticks.map((tick) => (
        <div key={tick} className="tick">
          {tick % 5 === 0 && <span className="label">{tick}</span>}
        </div>
      ))}
    </div>
  );
};

export default Ruler;

.ruler {
  display: flex;
  background: #f0f0f0;
  padding: 5px;
}

.ruler.horizontal {
  flex-direction: row;
  height: 30px;
}

.ruler.vertical {
  flex-direction: column;
  width: 30px;
}

.tick {
  flex: 1;
  position: relative;
}

.tick:after {
  content: '';
  position: absolute;
  background: #333;
}

.horizontal .tick:after {
  width: 1px;
  height: 10px;
  bottom: 0;
}

.vertical .tick:after {
  width: 10px;
  height: 1px;
  right: 0;
}

.label {
  position: absolute;
  font-size: 10px;
}

.horizontal .label {
  bottom: 15px;
}

.vertical .label {
  right: 15px;
}

使用SVG绘制标尺

SVG是绘制标尺的理想选择，因为它可以精确控制每个元素的位置和样式。

import React from 'react';

const SVGRuler = ({ width, height, isHorizontal }) => {
  const ticks = [];
  const majorTickLength = 15;
  const minorTickLength = 10;
  const tickSpacing = 10;

  for (let i = 0; i < (isHorizontal ? width : height); i += tickSpacing) {
    const isMajorTick = i % 50 === 0;
    ticks.push(
      isHorizontal ? (
        <line
          key={i}
          x1={i}
          y1={0}
          x2={i}
          y2={isMajorTick ? majorTickLength : minorTickLength}
          stroke="#000"
          strokeWidth="1"
        />
      ) : (
        <line
          key={i}
          x1={0}
          y1={i}
          x2={isMajorTick ? majorTickLength : minorTickLength}
          y2={i}
          stroke="#000"
          strokeWidth="1"
        />
      )
    );
  }

  return (
    <svg width={width} height={height}>
      {ticks}
    </svg>
  );
};

export default SVGRuler;

使用Canvas绘制动态标尺

Canvas适合需要高性能或动态更新的标尺实现。

import React, { useRef, useEffect } from 'react';

const CanvasRuler = ({ width, height, isHorizontal }) => {
  const canvasRef = useRef(null);

  useEffect(() => {
    const canvas = canvasRef.current;
    const ctx = canvas.getContext('2d');
    ctx.clearRect(0, 0, width, height);

    const tickSpacing = 10;
    const majorTickLength = 15;
    const minorTickLength = 10;

    ctx.strokeStyle = '#000';
    ctx.lineWidth = 1;

    if (isHorizontal) {
      for (let i = 0; i < width; i += tickSpacing) {
        const isMajorTick = i % 50 === 0;
        ctx.beginPath();
        ctx.moveTo(i, 0);
        ctx.lineTo(i, isMajorTick ? majorTickLength : minorTickLength);
        ctx.stroke();

        if (isMajorTick) {
          ctx.font = '10px Arial';
          ctx.fillText(i.toString(), i - 5, majorTickLength + 10);
        }
      }
    } else {
      for (let i = 0; i < height; i += tickSpacing) {
        const isMajorTick = i % 50 === 0;
        ctx.beginPath();
        ctx.moveTo(0, i);
        ctx.lineTo(isMajorTick ? majorTickLength : minorTickLength, i);
        ctx.stroke();

        if (isMajorTick) {
          ctx.save();
          ctx.translate(majorTickLength + 5, i + 5);
          ctx.rotate(-Math.PI / 2);
          ctx.font = '10px Arial';
          ctx.fillText(i.toString(), 0, 0);
          ctx.restore();
        }
      }
    }
  }, [width, height, isHorizontal]);

  return <canvas ref={canvasRef} width={width} height={height} />;
};

export default CanvasRuler;

使用第三方库

对于更复杂的需求，可以考虑使用专门的库如react-ruler或react-measure。

import React from 'react';
import Ruler from 'react-ruler';

const App = () => {
  return (
    <div style={{ position: 'relative', width: '500px', height: '30px' }}>
      <Ruler
        width={500}
        height={30}
        direction="horizontal"
        scale={1}
        unit="px"
        style={{ background: '#f5f5f5' }}
      />
    </div>
  );
};

export default App;
